P60 4K

  • 4K 6,100 RGB ANSI lumens
  • WPT™ w/Dual iris
  • NXL True solid-state illumination
  • 100,000 hours lifetime
  • 5 Year Limited Warranty
  • Native 4K@60–240Hz
  • Unify™
Contact Read more

Lenses

The P60 is driven by our new Unify® electronics platform with a quad DP1.4 interface to support both present and future applications, 4K, 6K and 8K. The powerful new Unify electronics allows the processing and display of native 4K content at up to 240Hz refresh rate.

Illuminated by our new Dual NXL™ hybrid light source, the P60 is perfectly suited for both front and rear projected systems. Like all other P-series projectors, the P60 is a true solid state illuminated product and designed for fixed and motion-base applications.

The P60 is designed with a low maintenance, solid state cooling system. Unify electronics provides tools for linear and predictable performance over time. The first and only scheduled maintenance on the P60 occurs after 50,000 hours and the 5 years standard warranty can be extended up to 10 years.

For consistent and linear color and brightness performance over time, the P60 is equipped with White Point Tracking.

All Norxe products are compatible with the N-series lenses.

Norxe P60 is available with IR for NVG stimulation.

Preliminary Specifications

Projector type Single chip DLP projector
Resolution 6K n-shift*, 4096 x 2176 (Native), 4096 x 2160 (DCI), 3840 x 2160 (UHD)
Brightness  6,100*² RGB ANSI lumens
Contrast ratio 3,100 – 12,000:1
Aspect ratio 1.88:1/1.90:1/16:9
Brightness uniformity 90%
Lens options N1: 0.70 – 1.09:1 @ 6K n-shift/4K Native
N2: 1.05 – 1.40:1 @ 6K n-shift/4K Native
N3: 0.55:1 @ 6K n-shift/4K Native
N4: 1.35:1 – 2.27:1 @ 6K n-shift/4K Native
Lens shift (max) Vertical up to 116% lens option dependentHorizontal up to 75% lens option dependent
Color correction P7
Light source(fully sealed optical architecture) SSI, NXL® + optional IR LED (standard IR wavelength is 740nm)
Illumination lifetime > 60,000 hours to 50% brightness (typical)
Optical block lifetime > 100,000 hours
Orientation Orientation free, no limitation
Inputs 4 x DisplayPort 1.4, 1 x HDMI 2.0
Input resolutions/Refresh 4096 x 2176. 4096 x 2176 – 1920 x 1200. 50Hz/60Hz/100Hz/120Hz/240Hz
3D Active – up to 4K@120Hz
Latency 18.4 ms @60Hz/10.2 ms @120Hz/5.2 ms @240Hz
Bit depth Up to 12-bit*³
Embedded Warp & Blend Yes
Control R, Ethernet, 2 x BNC (sync/trigger),1 x Mini DIN, 3.5 mm RC and mini-USB
Software tools Unify™ Web, Unify™ Desktop
Power Requirements 100 – 240V, 50 – 60Hz
Power Consumption 880 W typical, 975 W maximum
Heat Dissipation 3,000 BTU/hour typical, 3,325 BTU/hour maximum
Ambient Noise 35 dB A typical/37 dB A maximum
Operating temperature 0 to 40°C/32 to 104°F (0 to 3000m)
Storage temperature -20 to 60°C/-4 to 140°F
Operating humidity 20 to 80% (non-condensing)
Storage humidity 10 to 90% (non-condensing)
Dimensions (L x W x H)(height excl. removeable feet)  488x505x241 mm/ 19.68×19.88×9.49 inch
Weight 22.6 kg/49.8 Ibs
Standard accessories Power cord, IR remote control & lens lock fixings
Certifications TBC
Warranty Limited 5 years parts & labor (extendable up to 10 years)
24/7 Yes

Preliminary specifications subject to change without prior notice. Errors & omissions exempt.
*¹ – 6K n-shift resolution is achieved using an n-shift actuator. *² – Product configuration dependent. *³ – Bit depth dependent on total
bandwidth, limitations apply at higher refresh rates. *⁴ – Refer to User Guide for further information.
